Small-space wide-angle thermal imaging probe
The small-space wide-angle thermal imaging probe, with a wide-angle of up to 95 degrees, can achieve the largest possible area coverage at an extremely short detection distance. And the infrared temperature image of the detection surface is stably transmitted through the bus.
Product Overview：
The DVN2502 small-space wide-angle thermal imaging probe, with a wide-angle of up to 95 degrees, can achieve the largest possible area coverage at an extremely short detection distance. And the infrared temperature image of the detection surface is stably transmitted through the bus.
With a unique size of 4cm wide and 2cm thick, it can be easily applied in confined Spaces and still allow for free Angle adjustment. It is highly suitable for various small-space application scenarios such as cabins, boxes, and cabinets, and is easy to install and suitable for renovation.
This probe can view temperature data and images via the 485 interface.
Product specifications：
- The thermal imaging resolution is 160*120
- FOV-Horizontal 95°, FOV-Diagonal 119°
- Detector type: Vanadium oxide uncooled focal plane detector
- The pixel size is 12μm
- The response band is 8 to 14μm, and the package type is wafer-level
- Field of view (FOV) : 50.4°(H)×37.5°(V), 24°(H)×18°(V)
- Interface type: 485 bus, Ethernet
- Dimensions: 40mm*40mm*22mm
- Power supply mode: DC/24V
- Typical power consumption is 0.2W, and 0.75W when the shutter operates
- Waterproof rating: IP65
- Operating temperature: -30℃ to +75℃
Application scenarios：
- Electrical distribution cabinet
- Battery test equipment boxes, test cabinets, test racks
- Lithium battery safety testing laboratory
- Other power supply wiring cabinets
- Substation, transformer
